Dell'Orto carburetor cover aluminum PHBG DS 19 - 21 mm

15 mm intake manifold | Puch E50

Material: Aluminum · Area of application: Tuning · Ø inside: 14.5 mm · Ø External connection: 20 mm · Total length: 47 mm · Height flange center hole: 43 mm · Mounting type: Screws · Hole spacing inlet: 38 mm · Number of fixing points: 2 pcs · Camouflaged: Yes · Total height: 54 mm

Airsal 44 mm cylinder kit 65 ccm camouflaged | Puch

Nominal diameter: 44 mm · Manufacturer: Airsal · Material: Aluminum · Surface: sandblasted · Area of application: Tuning · Displacement: 65 ccm · Crankshaft stroke: 43 mm · Ø cylinder neck: 48 mm · Inlet window: 24 / 20 x 15 · Thread inlet: M6x1 (standard thread) · Ø outlet inside: 25 mm · Hole pattern [mm]: 44 x 44 · Ø piston pin (B): 12 mm · Hole spacing outlet: 42 mm · Outlet type: straight · Hole spacing inlet: 38 mm · Number of fixing points: 4 pcs · Thread outlet: M6x1 (standard thread) · Decompressor: Yes · Camouflaged: Yes

GPO bulb 12V - 3W (BA9s) 1-filament rear light

Manufacturer: GPO · Bulb holder: BA9s · Color: white · Tension: 12 V · Ø base: 9 mm · Total length: 23 mm · Performance: 3 W · Test mark: none · Ø Lamp head: 11 mm · LED: No

Dell'Orto gasket set carburetor PHBG

Manufacturer: Dell'Orto · Component group Carburetor: Sealing, revising · Carburetor type: PHBG

swiing® revival air filter screen Ø 52 mm original

Manufacturer: swiing® revival parts · Material: Steel · Surface: galvanized (blue) · Color: silver · Area of application: Standard · Ø outside: 52 mm · Height: 10 mm · Camouflaged: No

Dell'Orto hand choke lever PHBG

Manufacturer: Dell'Orto · Component group Carburetor: Choke control · Carburetor type: PHBG · Choke control: Hand choke

Dell'Orto 40° carburetor elbow set M6x0.75

Manufacturer: Dell'Orto · Width across flats nut: 7 mm · Material: Brass · Component group Carburetor: Adjusting screws, float, etc. · Surface: nickel-plated · Angle: 40 ° · Ø outside: 6 mm · Total length: 30.5 mm · Total length: 37.5 mm · Internal thread: MF5x0.75 (fine pitch thread) · Thread type: MF6x0.75 (fine pitch thread) · Height: 57 mm · Height: 67 mm

Dell'Orto 30° carburetor elbow set M6x0.75

Manufacturer: Dell'Orto · Width across flats nut: 7 mm · Material: Brass · Component group Carburetor: Adjusting screws, float, etc. · Surface: nickel-plated · Angle: 30 ° · Ø outside: 6 mm · Total length: 43 mm · Total length: 50 mm · Internal thread: MF5x0.75 (fine pitch thread) · Thread type: MF6x0.75 (fine pitch thread) · Height: 13 mm

Dell'Orto float chamber aluminum PHBG 15 - 21 mm

Manufacturer: Dell'Orto · Component group Carburetor: Adjusting screws, float, etc. · Material: Aluminum · Carburetor type: PHBG

Dell'Orto screw float chamber aluminum PHBG 15 - 21 mm

Manufacturer: Dell'Orto · Material: Aluminum · Drive: External hexagon · Screw head: Hexagon
